产品介绍：

1.数显(自动转塔）小负荷布氏硬度计，采用8寸触摸屏和高速ARM处理器，显示直观，人机互动友好，操作简便；运算速度快，数据库巨量存储，数据自动修正，并提供数据折线报表；

2. 机身使用优质铸铁一次浇铸成型，配合以汽车烤漆处理工艺，外形圆润美观；

3. 配置自动转塔功能,压头和镜头之间自动切换，使用更加方便；

4. 便捷控制系统，可自动进行全硬度标尺的单位转换；

5. 电子闭环控制施加试验力，完全实现了试验力的加荷、保荷、卸荷的自动化运行；

6. 可设置硬度值，当测试值超过设定范围时，发出报警音；

7. 具有软件硬度值修正功能，可以在一定范围内直接对硬度值进行修正；

8. 具有数据库功能，对试验数据自动进行分组保存，每组可保存10个数据，可以保存2000个以上数据；

9. 具有硬度值曲线显示功能，直观显示硬度值的变化；

10. 配置无线蓝牙打印机，并可通过RS232、USB接口输出数据；

11. 可选配CCD图像处理系统或视频测量装置；

12. 精度符合GB/T231.2-2018、ISO6506-2和美国ASTM E10标准。

Product Features:

● Digital (auto turret) small load Brinell hardness tester, adopt 8 -inch touch screen and high-speed ARM processor, Visual display, friendly man-machine interaction, easy operation, Fast operation speed, extensive database storage, data automatic correction, and provide data broken line report；

● The machine body is integral casting by high quality cast iron, with the automotive paint treatment process, the appearance is round and beautiful；

● Equipped with automatic turret function, automatic switching between the indenter and the lens, more convenient to use;

● Convenient control system can automatically convert the unit of full hardness scale；

● The electronic closed-loop control exerts the test force, fully realizes the automatic operation of loading,holding and unloading of the test force;

●The maximum and minimum hardness values can be set, when the test value exceeds the set range, an alarm sound will be issued；

●With the function of software hardness value correction, the hardness value can be directly corrected within a certain range；

● With the database function, the test data can be saved automatically in groups, each group can save 10 data, total can save more than 2000 data;

● With the hardness value curve display function, intuitive display the changes of hardness value;

● Equipped with wireless blue-tooth printer, the data can be output through RS232 and USB interface port；

● CCD image processing system or video measuring device is optional;

● Accuracy is in line with GB/T230.2, ISO6508-2 and American ASTM E18 standard.

主要技术参数：

Main Parameters:
